Features
1. The bottle inside wall washed by positioning flusging, washing mouth still fixed on the bracket, when the pump body contact with water and drainage holes, water through the nozzle pressurization flushing bottles head out of the bottle.
2. Simple structure, convenient maintanance.
3. Stainless Steel water storage barrel, elegant appearance
4. Suitable for small and medium enterprises.
5. With wide scope.
6. The outer wall of bottle adopts nozzle spray, inside of wall flushing, wash bottle sanitation and clean.
Spray.
7. Wash bottle by water or pressure of booster.
8. High productivity, suitable to SME.
9. Spray pressure can be adjusted by the size of the water inflow, applied to the different size and material of the new or old bottles washing.
กก
Parameters
| Model | GP-24 | Heads | 24 |
| Voltage | 220V | Washing Capacity | 1500-2000 Bottle/hour |
| Power | 5500W | Suitable for Bottle Height | 12-35cm(4.7-13.8In) |
| Automatic Grade | Semi-Automatic | Suitable for Bottle Diameter | 4-9cm(1.6-3.5In) |
| Control Mode | Electric | Material | SUS304 |
Operating Principle
1. The outer of the bottle washed by sprayer. And the spray pressure can be controlled by adjust the inflow.
2. Inner washing by anchor point.The spray was installed in holder. When valve body inflow water toched with water hole, it will spray ad washed the bottle.
Maintenance
1. Machine drive worm need refuel every day.
2. When you found the the washer was ineffective, first you need check the water pressure then check the controller was normal or not.
3. Check the soild piece of firmness at any time.
4. When you found the spray underpressure, pls poke the spray by iron wire. If it still not work, you need striked and washed it.
Item Included
 |
Item Number | Description | QTY | Unit | Note |
| 210024 | Semi-automatic 24 Bottles Washer 220V | 1 | Set | 220V |
