Mould Micro Air Grinder Ultrasonic File Polishing Machine Mold Turbo Lapping #300013

Description

1.The maximum air pressure can not exceed 8.0KG / CM2

2.When operating the tool, please do not wear jewelry, scarves, ties, etc., or wear loose clothing,

body and tools to maintain a certain distance

3.When you are not using tools, replacement parts, or servicing, turn off the

air supply and disconnect the tool from the air supply connector.

Special features:

1.The high torque of pneumatic turbine engine structure precise device can achieve good efficiency.

2. With multiple purposes of high-tech apex tool.

3. No heat, high efficient driver.

4. To control the speed of grinding in the form of air conditioning.

5. The hand of the ergonomics principle to design makes operation more comfortable.

Product introduction:

Rpm:35000

Stroke: 0.6 mm

package size :10.24*9.84*2.76 inch

Size: φ29 x200L

Air Consumption:0.08（m3/min）

weight :about 1.67lbs

Air pressue:90PSI

Colors: Black

Scope of application:

1. Mold polishing, mirror processing

2. Die casting to remove material overflow, remove burrs.

The characteristics and application:

1.Linear reciprocating, circumference of oscillating pneumatic ultrasonic grinding machine is

used.

2.pneumatic turbine engine structure technology, the advantages of small volume, feel is good.

3.low vibration ,low noise ,and the advantages of speed and torque.

4.It can use different jig for grinding operation.

5.can clamping industrial oil stone, ceramic fiber oilstone, file, or the grinding tools.

6.such as bamboo wood, the grooves in the mold or hardware products, wall, ribs.

7.R Angle, crack and other manual processing, not easily be fast grinding work.

8.so as to finish your work at once, surface repair mould roughing and mirror polishing.

9.can reduce work mould surface roughness rapidly until the lens, manual irreplaceable effect.

10get twice the result with half the effort quickly finish all kinds of work.
